Frequency Range
|
700-960/1710-2700
|
|
Bandwidth
|
260MHz / 990MHz
|
|
Gain
|
4/6dBi
|
|
Polarization
|
Vertical
|
|
Vertical Half-power Beam width
|
360°
|
|
Horizontal Half-power Beam width
|
55/30°
|
|
VSWR
|
≤1.5
|
|
Input Impedance
|
50Ω
|
|
Maximum input power
|
100W
|
|
Lightning protection
|
DC Ground
|
|
Input connector type
|
Sma male or Customized
|
|
Dimensions
|
Φ60*230mm
|
|
Antenna weight
|
0.56kg
|
|
Radome material
|
PVC
|
|
Radome color
|
White
|
|
Operating temperature
|
-40℃～60℃
|
|
Rated Wind Velocit
|
60m/s
|
|
Mounting way
|
Pole-holding
|
|
Mounting hardware
|
￠35mm～￠50mm
|
