Frequency Range
|
1710-2690MHz
|
|
|
Polarization
|
±45°
|
|
|
Bandwidth
|
980MHz
|
|
|
Gain
|
8dBi
|
|
|
Horizontal Half-power Beam Width
|
75°
|
|
|
Vertical Half-power Beam Width
|
55°
|
|
|
VSWR
|
≤1.5
|
|
|
Third-order Intercept Point
|
≤-97dBm
|
|
|
Isolation between ports (dB)
|
≥25dB
|
|
|
Cross-polar ratio
|
≥15dB@0º ≥10dB@+/-60º
|
|
|
Maximum input power
|
50Ω
|
|
|
Lightning protection
|
DC Ground
|
|
|
Input connector type
|
2 x N female or Customized
|
|
|
Dimensions
|
260*170*60mm
|
|
|
Antenna weight
|
0.72kg
|
|
|
Radome material
|
ABS
|
|
|
Radome color
|
White
|
|
|
Operating temperature
|
-40℃～60℃
|
|
|
Rated Wind Velocit
|
60m/s
|
|
|
Waterproof Standard
|
IP67
|
|
|
Mounting way
|
wall-hanging or pole-holding
|
|
|
Mounting hardware
|
￠35mm～￠50mm
|
|
